煤质活性炭在烟气脱硫中的应用
2011-11-15 09:13 来源:未知 点击数:

   燃煤排放的SO2是形成“酸雨”的主要原因之一,会给环境造成严重污染,同时,烟气中的SO2是生产硫酸、化肥和其他一系列重要化学品的基本原料,是一种不可忽视的硫资源。活性炭干法脱硫工艺具有脱硫过程耗水量少、无二次污染、脱硫后烟气温度高、硫便于回收等优点,目前已受到广泛应用。
    以烟煤为原料,采用气体活化法制备煤质活性炭,并将其用于烟气脱硫。制备煤质活性炭的佳工艺条件:碳化温度为600℃;碳化时间为1.0h;活化温度为900℃;活化时间为1.5h;水蒸气流量为406mL/min。活性炭的硫容随SO2、O2和水蒸气的体积分数的增加而增加;随反应器床层温度升高,活性炭的硫容先升高后下降。在床层温度为80℃,SO2、O2和水蒸气体积分数分别为0.5%、5.0%和12.0%,N2为载气的条件下,活性炭的硫容大,为72.3mg/g。
    The activated carbon for flue gas desulfurization was prepared from bituminous coal by gas activation process. Theoptimum preparation conditions are as follows: carbonization temperature 600 ℃, carbonization time 1.0 h, activationtemperature 900℃, activation time 1.5 h, steam flow 406 mL/min. The sulfur capacity of the activated carbon is increasedwith the increasing of volume fractions of SO2,O2 and steam, while increased at first and decreased subsequently with theincreasing of bed temperature. Under the conditions of bed temperature 80 ℃, volume fractions of SO2 0.5 %, O2 5% andsteam 12%, and N2 used as carrier gas, the highest sulfur capacity of the activated carbon is 72.3 mg/g.
    与木质和果壳活性炭相比,煤质活性炭具有原料来源广、价格低、易再生、抗磨损等优点,被广泛应用于水处理、溶剂回收、脱色净化、气体分离及气体净化等领域。本工作以烟煤为原料,采用气体活化法制备活性炭,并将其用于烟气脱硫,效果良好。
    于其它活性炭相比,煤质活性炭具有一定的优势,其将会有很好的发展趋势。
